Principle & Characteristics
This series product is manufactured with the international advanced “floating iteration technology". It is constructed by transforming step-down rectifying filtration, high power module adjustment, standard sampling amplifying and so on. The output voltage and current of this series product are optional for fixed or adjustable, one-way or multiple-way. It has excellent stability and wave coefficient, less noises, small size, novel style, stable property, and can be parallel or serial connected with the same specification product.
Scope of Application
It can be widely used in industrial productions laboratory in colleges, research institutes, post and telecommunications, automatic device and facilities.
Input voltage: AC220V ± 10%, 50Hz /60Hz
Output voltage: DC12VX 24 fixed; DC0-15Vs 0-30Vs 0-60V. 0-150V adjustable
Output current: DC 1A, 2A, 3A, 5A, 10A, 15A, 20A, 25A, 30A Voltage adjusting rate: 0.5%
Current adjusting rate: 1%
Wave restrain ratio: 65dB
Service environment: 4CTC, relative humidity< 90%, no corrosive gas
